A jacketed tilting pot is one of the most versatile machines a small manufacturer can own. It heats, melts, cooks and mixes in one vessel, then tips forward to empty, so there’s no ladling hot product by hand. SME Machinery builds stainless steel jacketed tilting pots in South Africa for food, cosmetic and chemical producers, from 50L start-up units to 500L+ production pots.
This guide covers how a jacketed tilting pot works, what it’s used for, which size and heating type to choose, and what to check before you buy.
What Is a Jacketed Tilting Pot?
A jacketed tilting pot (also called a tilting kettle or jacketed cooking pot) is a stainless steel vessel with a second outer wall, the jacket. Hot oil, water or steam circulates in the jacket and heats the product evenly from all sides instead of from a single hot spot underneath. The pot is mounted on a frame that lets it tilt forward, so the finished batch pours straight into containers, a filling line or a mixing tank. That saves scooping or pumping hot product, cuts labour and reduces the risk of contamination.
How It Works
- Heating medium: the jacket is filled with thermal oil, water or steam, heated by electric elements or an external steam supply.
- Even heating: heat surrounds the inner pot, so thick products are less likely to burn or stick.
- Mixing: an optional motorised agitator keeps the batch moving while it heats, which is essential for sauces, creams and wax blends.
- Tilting discharge: a hand wheel or motorised drive tips the pot forward to empty it safely and with less waste.
Oil jackets reach higher temperatures and suit products like wax, syrups and fudge. Water jackets are gentler and suit milk-based and delicate products. Our page on oil and water jacketed cooking pots explains the difference in more detail.
Applications
- Food: sauces, soups, curries, chutneys, atchar, jams, syrups, fudge, chocolate melting and dessert bases, and seasoning or spice pastes
- Cosmetics: creams, lotions, balms, lip balm and wax blends
- Pharmaceutical and natural products: ointments and herbal balms
- Chemical and detergent: liquid soap, polish, detergent gels and pastes
Key Features
- Food-grade stainless steel (SS304 or SS316) contact parts
- Electric, oil-jacket or steam heating options
- Manual or motorised tilting
- Temperature control with a safety valve
- Optional agitator or stirrer
- Capacities from 50L to 500L and above
Sizes and Configurations
Our oil-jacketed tilting pots come in the sizes below, all with SS304 food-grade stainless steel, temperature control and a safety valve as standard. Every pot can also be built to order, so the heating type, tilt mechanism and agitator can be matched to your product.
| Capacity | Tilting | Suits | Est. price |
|---|---|---|---|
| 70L | Manual | Start-ups, test batches, small cosmetic runs | R25,000 |
| 135L | Manual | Small food and cosmetic producers | R30,000 |
| 235L | Manual or motorised | Growing producers, sauces and jams | R40,000 |
| 300L | Motorised | Established producers running daily batches | R65,000 |
| 500L | Heavy-duty motorised | Factories and high-volume lines | R81,000 |
| 1000L | Custom build | Large-scale processing | Custom quote |
Prices shown are estimates for the standard oil-jacketed pot. The final price depends on capacity, heating type, the grade of stainless steel and whether you add an agitator or motorised tilt. Contact us with your product and batch size for a quote.
How to Choose the Right Tilting Pot
- Batch size: size the pot to your typical batch, not your biggest. A pot run at 60–80% of capacity heats and mixes best.
- Product viscosity: thick products need an agitator with enough torque, and often a scraper blade.
- Maximum temperature: high-temperature products need an oil jacket. Gentle heating suits a water jacket.
- Power supply: larger electric pots usually need three-phase power, so check your premises first.
- Discharge height: make sure the tilted pot pours cleanly into your containers or filling machine.
If your product needs high-shear emulsifying as well as heating, as most creams and lotions do, consider a homogenizer tilting jacketed mixing tank instead. For larger fixed installations, see our oil and water jacketed mixing tanks.
Why Choose SME Machinery
- Manufactured and supported in South Africa
- Custom sizes, heating systems and agitators built to order
- Spare parts and service available locally
- Setup guidance and operator training
- Equipment for start-ups through to established production plants
Frequently Asked Questions
What is the difference between a tilting pot and a jacketed mixing tank? A tilting pot empties by tipping forward, which suits thick products and smaller batches. A jacketed mixing tank is fixed and empties through a bottom valve, which suits larger volumes and pumpable liquids.
Can a tilting pot be used for cosmetics and food? Yes, if the contact parts are food-grade stainless steel. Clean the pot thoroughly between product types, and don’t use the same pot for food and chemical products.
Do I need an agitator? For thin liquids, stirring by hand may be enough at small volumes. For sauces, creams, wax blends and anything that can catch on the bottom, a motorised agitator gives a better, safer and more consistent result.
Oil Jacketed vs Steam Jacketed vs Water Jacketed Pots
| Heating type | How it works | Best for |
|---|---|---|
| Oil jacketed (thermal oil) | Electric elements heat oil in the jacket, which heats the pot evenly | High temperatures without a boiler: sauces, jams, atchar, caramel. Popular with small and medium producers. |
| Steam jacketed | Steam from a boiler circulates through the jacket | Factories that already have steam; very fast heating for large batches. |
| Water jacketed (bain-marie) | Hot water in the jacket gives gentle heat | Chocolate, dairy, delicate products that scorch easily. |
Many buyers searching for an oil jacketed pot for sale in South Africa choose oil because it needs no boiler and reaches higher temperatures than water. See our oil and water jacketed cooking pots.
Jacketed Kettle with Mixer: Why the Stirrer Matters
Thick products like jam, fudge, atchar and pap stick and burn on the bottom of a pot. A built-in scraper or anchor stirrer keeps the product moving and scrapes the hot surface, so you get an even cook without someone stirring by hand. For products that also need emulsifying, consider a jacketed tilting mixing tank with a homogenizer.
Who Buys Jacketed Tilting Pots?
- Sauce, chutney and atchar manufacturers (see sauce filling machines for the next step)
- Jam, preserves and confectionery producers
- Caterers, hospitals, school feeding schemes and canteens cooking large volumes
- Butcheries making pies, gravies and cooked fillings
- Cosmetic manufacturers melting waxes and butters
Small vs Large Jacketed Pots
A small jacketed pot (around 50–135 litres) suits start-ups and test kitchens. Large pots of 300–1000 litres are used by factories and caterers. Remember that a pot should not be filled to the brim when cooking and stirring, so size it on about 70–80% of the total volume.
Jacketed Cooking Pots in Gauteng
SME Machinery is based in Germiston on the East Rand, so buyers across Gauteng can visit the factory to see a jacketed tilting pot before they order. We deliver and install throughout South Africa, with local landing pages for Johannesburg, Pretoria and Centurion and the East Rand. See all our service areas.
More Questions About Jacketed Pots
What is the difference between an oil jacketed and a steam jacketed pot?
An oil jacketed pot heats itself with electric elements and thermal oil, so it needs no boiler. A steam jacketed pot needs a steam supply but heats very quickly.
Why buy a tilting pot?
Tilting lets you pour out heavy, hot product safely and quickly, instead of scooping it out by hand.
Can the pot have a mixer?
Yes. Most of our pots can be fitted with an anchor or scraper stirrer to stop thick products burning.
Which steel is used?
Food-grade stainless steel on all product contact surfaces.
Get a Quote on a Jacketed Tilting Pot from SME Machinery
SME Machinery designs and manufactures jacketed tilting pots to your specification at our factory in Germiston, and we deliver and install across Gauteng and South Africa. Tell us what you produce, your batch size and your daily output, and we will recommend the right machine and send you a quote.
- Call or WhatsApp: 073 646 5211
- Email: info@smemachinery.co.za
- Visit: 8 Moller Street, Factory C2, Germiston South (Mon–Sat, 7am–5pm)
- Need to spread the cost? See our rent-to-own and finance options.
Final Thoughts
A jacketed tilting pot gives small and medium manufacturers controlled heating, mixing and easy discharge in one machine. Choose the size, heating type and agitator to suit your product, and the pot will do the work of several pieces of equipment. See our jacketed cooking pots range, or contact SME Machinery on +27 73 646 5211 for a quote.
